A backyard pavilion with a stone pillar and metal roof, surrounded by trees, and a paved area with small garden beds and pathway lights.

Sedona Pavilions

Specifications

Rough Sawn Components

Posts: 8″ × 8″

Beams: 6″ × 10″, Ridge Beam: 6″ × 8″

Hip Rafters: 6”x8”, Main Rafters: 6″ × 6″

Braces: 4″ × 8″, Gutter Boards: 2”x8'“

Smooth Components:

Tongue and Groove: 1”x8”

*Listed sizes are nominal sizes, actual sizes may vary per piece.

A diagram showing the customization options for a product, including size measurements from 10x10 up to 20x20, with additional posts available for larger sizes.
Closet with a price range sign indicating $10,580 to $30,580.
Black silhouette of three tall pine trees on a beige background with the text 'Variety. Eastern White Pine' below.
Line drawing of a hand holding a speech bubble with a question mark inside it, next to the text 'Build Difficultly' and 'Advanced'.

Stain Options

Natural

Aspen

Close-up of a textured wooden surface with natural grain and color variations.
Close-up of a wooden surface with a visible wood grain pattern.

Pecan

Dark Walnut

Close-up of a wooden surface with visible grain and texture.
Close-up of a wooden surface with dark and light brown tones.

Mahogany

Charwood

Close-up of a dark, textured wooden surface.
Close-up of a dark, textured wooden surface.

Roofing

Burnt Hickory

Driftwood

Metal:

Empty white background with no objects or details.
A close-up view of a beige background.
A plain, solid beige background with no distinguishable objects or features.
A beige background.
Close-up of a brown textured surface, possibly leather or fabric.
A plain, solid dark gray background with no objects or details.
A plain gray background with a subtle gradient effect.
A close-up of a textured dark surface, possibly metal or painted material.
A black background
A red background with no distinguishable objects or details.
A brown background with no distinguishable objects or features.
A solid dark red background with no distinguishable objects or features.

Black

Bright Red

Rustic Red

Burgundy

Blue color
Empty dark blue screen or background.
Green color

Gallery Blue

Hawaiian Blue

Green

Shingles:

Light Stone

White

Clay

Tan

Antique Bronze

Brown

Light Gray

Charcoal

Close-up of a brown wooden surface with visible wood grain.
Close-up of a wooden surface with visible grain and texture.
Close-up of a gray asphalt shingle roof showing overlapping rectangular shingles.
Close-up of black asphalt roof shingles arranged in a layered pattern.
Close-up of gray asphalt shingles on a roof

Cobblestone Gray

Moire Black

Georgetown Gray

Close-up of brown asphalt shingles on a roof.
Close-up of brown asphalt shingles on a roof.
Close-up view of a roof with reddish-brown asphalt shingles arranged in overlapping rows.

Heather Blend

Weathered Wood

Burnt Sienna

A computer screen displaying a 3D model of a small wooden pavilion with a dark roof on a gray base.
See Your Colors at Work!

  • The Sedona features our signature heavy timber framing: 8″ × 8″ posts, 6″ × 10″ main beams, 6″ × 8″ ridge beam, 6”x8” hip rafters, 6″ × 6″ main rafters, and 4″ × 8″ braces. All timbers are rough‑sawn Eastern White Pine, sanded and finished with an oil‑based stain + sealer for durability.

  • A popular size is a 14’x14’ footprint. The footprint is measured from outside of one post to the outside of the next. The roofline is the footprint + the overhang, which is 1’6” on each side of the Sedona. On a 14’x14’ Sedona, the roofline would be 17’x17’. The standard roof pitch is 7/12.

  • We offer 8 different stain colors. Our stain is an oil-based stain and sealer. For roofing, we offer residential rib‑panel metal roof, and CertainTeed dimensional shingles. Our add on options include integrated wiring channels, privacy walls, metal fascia, PVC post sleeves, and engineered drawings.

  • All of kits are designed for DIY or contractor‑assisted assembly: every piece is pre‑cut, and ready for assembly. Heavy equipment is not required, and the build can typically be completed in a weekend. The Sedona is slightly more intensive to DIY because of all of the precise fitting.

  • The Sedona features real timber beams and its signature exposed rafter system, showcasing our custom craftsmanship. Like the Burbank, it’s designed to host gatherings, for outdoor kitchens, to provide shade and shelter, to elevate the look and feel of outdoor living, and whatever else you may need it for!

Additional Information

Available Add-Ons (Extra Charge)

  • Integrated Wiring Channels

  • Privacy Walls

  • Engineered Drawings

  • PVC Post Sleeves

  • Fascia

Get a Custom Quote!
A wooden pavilion with a sloped roof and stone foundation, featuring electrical outlets and wires along a concrete floor.

Privacy Walls

The image shows the front of a wooden pavilion with a dark roof, situated in a wooded area with trees bearing autumn-colored leaves.

Fascia

Yellow electrical wires installed on a wooden post under a patio with a wooden roof, with a house and outdoor furniture in the background.

Integrated Wiring

Construction site featuring a small structure with a black shingled roof, wooden support beams, and white horizontal siding. Gravel ground in front, surrounded by trees and a partly cloudy sky.

PVC Post Sleeves

Wooden outdoor shelter under construction, with concrete and gravel foundation, surrounded by trees and construction materials.
Close-up of a wooden and stone structure near a pond, with a gravel pathway marked with orange spray paint. In the background, there are trees, a grassy area, and houses under a clear blue sky.
A wooden carport with stone and concrete pillar supports, situated on a green lawn with trees in the background.
An outdoor pavilion with a new concrete fireplace, some paint cans on a shelf, and a partially constructed wooden wall, with houses and green lawns in the background.
Construction site with a small building on a gravel foundation, surrounded by trees, with a blue sky and some clouds overhead.
View of a wooden gazebo with a pitched roof, showing the interior ceiling with exposed beams and wood paneling, and a background of a house and trees.
A backyard with an in-ground swimming pool covered with a gray pool cover, surrounded by a concrete deck. There is a wooden structure with a black roof at the back, and a large tree with green leaves behind it. A person is walking along the fence on

The Timberscapes Difference

  • Close-up of the underside of a wooden deck or porch, showing wooden beams and planks with a grassy field, trees, and houses in the background.

    ✓ No Exposed Beams

    We tuck our beams in, not only so they sleep better at night, but you’ll sleep better too knowing your beams are protected from standing water and rot.

  • Close-up of a building's wooden porch support beams and stone foundation with a lake and trees in the background on a sunny day.

    ✓ Oversized Profiles

    Larger post, beams, and rafters means less sagging, and less sadness. Bigger is better, and pavilions are no exception. Nobody ever wished for smaller pavilion, that’s just a fact!

  • A person working on a construction project outdoors, installing a wooden beam on top of a stone wall with ladders nearby and trees in the background.

    ✓ Streamlined Assembly

    Built to contractor grade standards, we cut every piece with precision, so you can have peace. Pre-cut for efficient contractor assembly, or tackled by the capable homeowner.

  • Construction of a small shelter with a gravel pathway, wooden supports, and a dark gray roof, surrounded by trees under a blue sky.

    ✓ Unlimited Customization

    Want to add a post or two? You can do that! Integrated storage room? Yep! We’re here to help you make your dream space, so the sky’s the limit!

  • Close-up of wooden playset beam with a backyard scene including a pond, trees, a wooden fence, and a blue slide in the background.

    ✓ Top Notch Quality

    We take pride in our craftsmanship. We don’t cut corners, we make them look beautiful. Quality is in the details, and we’re all about the details!

  • A 3D model of a small wooden gazebo with a dark roof on a white platform, surrounded by color swatches of wood and wall textures.

    ✓ Online Design Tools

    Timberscapes makes it easy to get information, visualize, and quote your structure all online! Try out the visualizer, but only if you like to have a good time.
